    Features
    • Advanced inverter for stable performance
      Provides stable, clean power with total harmonic distortion (THD < 3%) to protect sensitive electronics like computers, instruments, and communication equipment.
    • Compact open-frame design for easy mobility
      The open-frame structure provides a smaller overall size, reducing weight, and a more compact footprint, facilitating ease of movement and transportation for outdoor tasks, emergency scenarios, or temporary power supply.
    • Smart fuel-saving system
      The open frame inverter generator is equipped with intelligent variable-speed control, the generator automatically adjusts engine speed based on load, reducing fuel consumption and emissions under light-load conditions.
    • Quick-start function
      Features electric start (with recoil start backup on select models), enabling fast and reliable power restoration in case of outages.
    • Rugged and easy maintenance
      Built with a high-quality engine and efficient inverter alternator that offer excellent cooling performance and overload resistance. The open layout makes routine maintenance quick and convenient.
    • Parallel connection power expansion
      Supports parallel operation, allowing multiple compatible units to be connected for increased output and handling higher power demands.
    Specifications
    Genset Model DB6500iE 5kW Open Frame Gasoline Inverter Generator DB13000iE 10kW Open Frame Gasoline Inverter Generator DB25000iE 20kW Open Frame Gasoline Inverter Generator
    Alternator Excitation Mode PMG inverter type
    Rated Power (kW) 10 20 5
    Max. Power (kW) 11 21 5.5
    Rated Voltage (V) 220 & 380 (double voltage) 220 & 380 (double voltage) 220
    Rated Frequency (Hz) 50 50 50
    Phase Single & three phase (double voltage) Single & three phase (double voltage) Single phase
    Power Factor (COSφ) 1.0 & 0.8 1.0 & 0.8 1.0
    Insulation Class F F F
    Engine Engine Model DH550 DH999 DH275
    Bore Size×Stroke (mm) 94×76 90×78.5 75×62
    Displacement (cc) 550 999 275
    Engine Type 1 cylinder, air-cooled, OHV (overhead valve) 2 cylinder, air-cooled, OHV (overhead valve) 1 cylinder, air-cooled, OHV (overhead valve)
    Fuel Type Gasoline Gasoline Gasoline
    Oil Capacity (L) 1.2 2.4 0.7
    Starting System Recoil/Electric Start Electric Start Recoil/Electric Start
    Genset Fuel Tank (L) 35 35 20
    Noise Level (dBA/7m) 78 85 75
    Dimension (mm) 703×611×686 815×625×937 600×430×620
    Weight (kg) 85 155 50
