    Features
    • High-efficiency rare-earth permanent magnet generator
      The air-cooled gasoline welding genset features a rare-earth (RE) permanent magnet (PM) generator that provides stable current and excellent overload capacity—achieving up to 20% higher efficiency than traditional generators.
    • Compact and lightweight
      Designed with high mobility and easy storage, with a minimal footprint and light weight, making it suitable for mobile welding and outdoor field tasks.
    • Adjustable welding current
      This gasoline-powered welding generator allows for simple, continuous adjustment of the welding current, offering better control and weld quality to meet various on-site welding requirements.
    Specifications
    Model DB-AXQ-120A DB-AXQ-180A
    Welder Welding Type Manual welding
    No-Load Voltage (V) 60-70 60-70
    Welding Voltage (V) 22-28 22-28
    Welding Current (A) 120 180
    Load Continuous Rate 60% 60%
    Auxiliary Power AC220V/1kW AC220V/4kW
    Engine Engine Model 225-V 225-V
    Engine Type 1 cylinder, air-cooled, OHV (overhead valve)
    Bore Size×Stroke (mm) 70×55 70×55
    Displacement (cc) 225 225
    Starting System Recoil start
    Oil Capacity (L) 0.6 0.6
    Generator Fuel Tank Capacity (L) 15 15
    Noise Level (dBA/7m) 78 78
    Dimension 560×490×540 560×490×540
    Weight (kg) 40 45
