10kW-20kW Gasoline Genset

Air-Cooled Silent Gasoline Generators (Twin Cylinder)

Air-Cooled Silent Gasoline Generators (Twin Cylinder)
  • Air-Cooled Silent Gasoline Generators (Twin Cylinder)
  • Air-Cooled Silent Gasoline Generators (Twin Cylinder)
  • Air-Cooled Silent Gasoline Generators (Twin Cylinder)

    • 10kW-20kW Gasoline Genset

    Air-Cooled Silent Gasoline Generators (Twin Cylinder)

    Automatic Transfer Switch (ATS)

    The generator is compatible with a fully automatic ATS control panel, which features status indicators for utility power, generator operation, automatic mode, and fault alarms.
    When the ATS detects a utility power outage, the generator will start automatically, and the ATS will transition the power supply to the generator. Once utility power is restored, the system will implement a delay shutdown period of 30 to 60 minutes, after which the ATS will automatically switch back to grid power.
    The ATS configuration guarantees an uninterrupted power supply with seamless transitions, supported by a vertical single-cylinder, 4-stroke, forced air-cooled engine recognized for low emissions and stable performance.

    Request a Quote
    Features
    • The gasoline generator is powered by a V-type twin-cylinder, 4-stroke, forced air-cooled engine for stable output and low emissions. Built to handle medium to heavy-duty loads in a variety of environments.
    • The genset is equipped with a full copper alternator and an automatic voltage regulator (AVR), ensuring steady voltage output, reliable excitation, and protection for sensitive equipment.
    • Reinforced with a heavy-duty steel frame, the gasoline genset comes standard with caster wheels, allowing smooth transport and deployment in varied environments.
    • The silent gasoline genset is equipped with complete safety measures, including overload protection and low oil shutdown to extend service life and safeguard the generator during high-load use.
    • Equipped with a specially optimized silencing system to effectively minimize noise levels—perfect for settings that demand quieter power solutions.
    Product Details
    • Air-Cooled Silent Gasoline Generators (Twin Cylinder)
    • Air-Cooled Silent Gasoline Generators (Twin Cylinder)
    • Air-Cooled Silent Gasoline Generators (Twin Cylinder)
    Specifications
    Genset Model DB12500ES 10kW Silent Gasoline Generator DB15000ES 12kW Silent Gasoline Generator DB18000ES 15kW Silent Gasoline Generator DB20000ES 20kW Silent Gasoline Generator
    Alternator Excitation Mode Brushed, self-excitation, AVR (automatic voltage regulation)
    Prime Power (kW) 10 12 15 18
    Standby Power (kW) 10.5 13 16 20
    Rated Voltage (V) 220/380 220/380 220/380 220/380
    Rated Frequency (Hz) 50 50 50 50
    Phase Single phase
    Three phase
    Power Factor (COSφ) 1/0.8 1/0.8 1/0.8 1/0.8
    Insulation Class F F F F
    Engine Engine Model DH740 DH760 DH999 DH999
    Bore Size×Stroke (mm) 78×70 82×76 90×78.5 90×78.5
    Displacement (cc) 740 760 999 999
    Engine Type 2 cylinder, air-cooled, OHV (overhead valve)
    Fuel Type Gasoline
    Oil Capacity (L) 1.6 1.6 2.4 2.4
    Starting System Electric Start
    Genset Fuel Tank (L) 30 30 30 30
    Noise Level (dBA/7m) 75 75 75 75
    Dimension (mm) 1150×750×870 1150×750×870 1300×800×930 1300×800×930
    Weight (kg) 245 260 310 320
