Product Details
Specifications
| Genset Model |
DB6500C 5kW Open Frame Diesel Generator |
DB10000C 6kW Open Frame Diesel Generator |
YD12000C 8kW Open Frame Diesel Generator |
| Alternator |
Excitation Mode |
Brushed, self-excitation, AVR (automatic voltage regulation) |
| Prime Power (kW) |
6 |
8 |
8 |
| Standby Power (kW) |
6.5 |
8.5 |
8.5 |
| Rated Voltage (V) |
220 |
220 |
220 |
| Frequency (Hz) |
50 |
50 |
50 |
| Phase |
Single phase |
| Power Factor (COSφ) |
1 |
1 |
1 |
| Insulation Class |
F |
F |
F |
| Engine |
Engine Model |
KD192FE |
KD1100FE |
KD1100FE |
| Bore Size×Stroke (mm) |
92×75 |
100×85 |
100×85 |
| Displacement (cc) |
499 |
668 |
668 |
| Engine Type |
1 cylinder, air-cooled, direct injection |
| Fuel Type |
Diesel |
| Oil Capacity (L) |
1.5 |
2 |
2 |
| Starting System |
Recoil/Electric Start |
| Genset |
Fuel Tank (L) |
20 |
25 |
25 |
| Noise Level (dBA/7m) |
83 |
85 |
85 |
| Dimension (mm) |
780×520×685 |
785×575×890 |
785×575×890 |
| Weight (kg) |
123 |
148 |
148 |
Automatic Transfer Switch (ATS)
The generator is compatible with a fully automatic ATS control panel, which features status indicators for utility power, generator operation, automatic mode, and fault alarms.
When the ATS detects a utility power outage, the generator will start automatically, and the ATS will transition the power supply to the generator. Once utility power is restored, the system will implement a delay shutdown period of 30 to 60 minutes, after which the ATS will automatically switch back to grid power.
The ATS configuration guarantees an uninterrupted power supply with seamless transitions, supported by a vertical single-cylinder, 4-stroke, forced air-cooled engine recognized for low emissions and stable performance.
