10kW-20kW Diesel Genset

Air-Cooled Open Frame Diesel Generators (2 Cylinder)

Air-Cooled Open Frame Diesel Generators (2 Cylinder)
  • Air-Cooled Open Frame Diesel Generators (2 Cylinder)
  • Air-Cooled Open Frame Diesel Generators (2 Cylinder)
  • Air-Cooled Open Frame Diesel Generators (2 Cylinder)

    • 10kW-20kW Diesel Genset

    Air-Cooled Open Frame Diesel Generators (2 Cylinder)

    • Air-Cooled Open Frame Diesel Generators (2 Cylinder)
    • Air-Cooled Open Frame Diesel Generators (2 Cylinder)
    • Air-Cooled Open Frame Diesel Generators (2 Cylinder)
    • Air-Cooled Open Frame Diesel Generators (2 Cylinder)
    Request a Quote
    Specifications
    Genset Model DB12500C 10kW Open Frame Diesel Generator DB15000C 12kW Open Frame Diesel Generator DB18000C 15kW Open Frame Diesel Generator DB25000C 20kW Open Frame Diesel Generator
    Alternator Excitation Mode Brushed, self-excitation, AVR (automatic voltage regulation)
    Prime Power (kW) 12 15 18 10
    Standby Power (kW) 13 16 20 10.5
    Rated Voltage (V) 220/380 220/380 220/380 220/380
    Frequency (Hz) 50 50 50 50
    Phase Single phase
    Three phase
    Power Factor (COSφ) 1/0.8 1/0.8 1/0.8 1/0.8
    Insulation Class F F F F
    Engine Engine Model KD292 2V95 2V98 KD2V88
    Bore Size×Stroke (mm) 92×75 95×75 98×88 88×72
    Displacement (cc) 997 1247 1326 836
    Engine Type 2 cylinder, air-cooled, direct injection
    Fuel Type Diesel
    Oil Capacity (L) 2.5 3.2 3.2 2
    Starting System Electric Start
    Genset Fuel Tank (L) 30 30 30 30
    Noise Level (dBA/7m) 87 90 90 87
    Dimension (mm) 860×650×800 1100×700×790 1100×700×790 960×670×720
    Weight (kg) 202 236 248 186
